A0CC00087-00 - (12v) / A0CC00087-00 - (24v)
Type
Applications
Voltage
12,24
Dimensions
L:385 - H:181 - W:594
Technical Data
| Code | Voltage (V) | Air (m3/h) | Heating (Kw) | Cooling (Kw) | Amper (A) | Weight (Kg) |
|---|---|---|---|---|---|---|
| A0CC00087-00 | 12 | 690 | 6 | - | 15.5 | 5.8 |
| A0CC00088-00 | 24 | 690 | 6 | - | 8.5 | 5.8 |
| Code | A0CC00087-00 |
|---|---|
| Voltage (V) | 12 |
| Air (m3/h) | 690 |
| Heating (Kw) | 6 |
| Cooling (Kw) | - |
| Amper (A) | 15.5 |
| Weight (Kg) | 5.8 |
| Code | A0CC00088-00 |
|---|---|
| Voltage (V) | 24 |
| Air (m3/h) | 690 |
| Heating (Kw) | 6 |
| Cooling (Kw) | - |
| Amper (A) | 8.5 |
| Weight (Kg) | 5.8 |
