A00300ES - A00300ES/1 (12v) / A00301ES (24v)
Part. A00300ES: puller
Part. A00300ES/1: pusher
Part. A00301ES: puller
Technical Data
| Code | Voltage (V) | Air (m3/h) | Dissipable thermal power (Kcal/h) | Fin pitch (mm) | Amper (A) | Weight (Kg) |
|---|---|---|---|---|---|---|
| A00300ES - A00300ES/1 | 12v | 3x620 | 5000 | 3.25 | 3x4.4 | 10 |
| A00301ES | 24 | 3x650 | 5000 | 3.25 | 3x2.4 | 10 |
| Code | A00300ES - A00300ES/1 |
|---|---|
| Voltage (V) | 12v |
| Air (m3/h) | 3x620 |
| Dissipable thermal power (Kcal/h) | 5000 |
| Fin pitch (mm) | 3.25 |
| Amper (A) | 3x4.4 |
| Weight (Kg) | 10 |
| Code | A00301ES |
|---|---|
| Voltage (V) | 24 |
| Air (m3/h) | 3x650 |
| Dissipable thermal power (Kcal/h) | 5000 |
| Fin pitch (mm) | 3.25 |
| Amper (A) | 3x2.4 |
| Weight (Kg) | 10 |
