Hydraulic motor
Theorical Displacement: 11.1 cm3/giro
Minimum speed: 600 gir/min.
Maximum speed: 3500 gir/min.
Continuos maximum pressure: 270 bar
Capacity: 16,15 L/min
Torque at 100 bar: 15,02 Nm
Parameters
Displacement: 154cc
Operating speed: 7000rpm Max.continuos
Refrigerant: R-134a
Rotation: clockwise
Condenser
Serpentine condenser: 6500Kcal/h (fin pitch 2,1mm)
Axial motor fan: 2x1080 m3/h
Technical Data
| Code | Voltage (V) | Model |
|---|---|---|
| AE042AS | 12 | Unidirezionale rotazione destra |
| AE043AS | 24 | Unidirezionale rotazione destra |
| Code | AE042AS |
|---|---|
| Voltage (V) | 12 |
| Model | Unidirezionale rotazione destra |
| Code | AE043AS |
|---|---|
| Voltage (V) | 24 |
| Model | Unidirezionale rotazione destra |
